Securonix Threat Labs Initial Coverage Advisory: F5 BIG-IP Vulnerability (CVE-2022-1388) Detection Using Security Analytics

Threat Research
Share

By Securonix Threat Labs, Threat Research: Den Luzvyk, Tim Peck

Updated May 12, 2022



Introduction

A new critical CVE has just come to light which targets a vulnerability in iControl REST functionality in F5 systems. The critical CVE (CVE-2022-1388) which is classified as an authentication bypass vulnerability carries a 9.8/10 severity rating. The overall impact is vast as it affects the current line of network appliances such as the F5 BIG-IP systems. These include modern firewalls and network monitoring and performance hardware.

Currently, the vulnerability has been patched and F5 has disclosed in its latest KB update. F5 customers should patch immediately as it is currently being exploited in the wild.



Attack Chain & Scope

The scope of the vulnerability is not limited to just authentication bypass. Properly exploited, an attacker has the ability to execute UNIX-based commands remotely which could give them full control over the appliance. Affected versions include:



Appliance Version Status
F5 BIG-IP: 16.1.0 – 16.1.2 Patched in 16.1.2.2
F5 BIG-IP: 15.1.0 – 15.1.5 Patched in 15.1.5.1
F5 BIG-IP 14.1.0 – 14.1.4 Patched in 14.1.4.6
F5 BIG-IP 13.1.0 – 13.1.4 Patched in 13.1.5
F5 BIG-IP 12.1.0 – 12.1.6 UNSUPPORTED
F5 BIG-IP 11.6.1 – 11.6.5 UNSUPPORTED



Overall, the exploit is incredibly easy to run against remote F5 systems. In fact several PoC scripts written in Python or even using the CMD command Curl have been spotted in the wild. At this point it’s almost point and click to execute root commands in the remote F5 appliance which can be seen in Figure 0 below.

Figure 0



The exploit requires very little data and takes advantage of the iControl REST to allow for authentication bypass and eventually remote code execution (RCE). As you can see in the exploit code below, an attacker would need very little information about the target system (figure 1).

Figure 1



According to public information available on sites such as Shodan, we see a large number of public facing sites that fall under this target category (figure 2).

Figure 2



Conclusion

The overall impact could be incredibly detrimental to the organization’s network integrity. Given the exploit carries both an authentication bypass as well as remote code execution techniques, we advise organizations to take extra precautions and to implement mitigation strategies we recommend below.



Securonix Recommendations & Mitigations

  • Patch affected systems to the latest KB provided by F5
  • Block iControl REST access through local IP address ranges (ie: 127.0.0.1)
  • Restrict management interface to trusted management networks or vLANs.
  • Perform forensic analysis to ensure no past compromise
    • /var/log/audit
    • /var/log/restjavad-audit.0.log

Detections

Seeder Hunting Queries:

  • rg_functionality=”Next Generation Firewall” AND requesturl CONTAINS “/mgmt/tm/util/bash”
  • rg_functionality=”Firewall” AND requesturl CONTAINS “/mgmt/tm/util/bash”
  • rg_functionality=”Web Proxy” AND requesturl CONTAINS “/mgmt/tm/util/bash”
  • rg_functionality = “Traffic Manager” and rg_vendor = “F5 Networks” and deviceseverity = “notice” and resourcecustomfield2 = “Command OK” and resourcecustomfield4 CONTAINS “cmd_data=run” and resourcecustomfield4 CONTAINS ” -c “



Securonix Coverage:

  1. Possible CVE-2022-1388 Exploitation Attempt F5 Audit Analytic
  2. Possible CVE-2022-1388 Exploitation Attempt URLs Access Analytic
